M-Board
Built to withstand more construction site conditions
Increased Durability:
Perfect for heavy duty use across multiple applications
Three-Layer Design
To provide enhanced structural strength, extended service life, and excellent dimensional stability under demanding conditions
Sustainability
ACROW Board is a sustainable material which is made of up to 50% recycled content, helping to significantly reduce waste, energy consumption, and resource demand. Its durability, recyclability, and cost effectiveness contribute to a circular economy and provide a wide range of environmental benefits
Product Benefits
We can provide our clients with cut to length according to the required measurements, increasing efficiency and avoiding any waste
Weather Resistance
Durable
Easy to Clean
Fire Retardant
Cost Effective
Water Resistant
Easy To Install
Termite Resistant
Ready Tie Rod Hols
Size Available Upon Request
Product Specifications
Dimensions (Mm)
Customizable upon request
Length: up to 6000mm, width: up to 1500mm
Thickness: 6mm, up to 30mm with intervals each 0.50mm
Tolerance (Mm)
Length ± 0.5mm/M
Width ± 0.5mm/M
Thickness ± 0.3mm
Number Of Uses In Framed Formwork Panels
Up to 200 times (according to handling)
Number Of Uses In Traditional Frameless System
Up to 50 times (according to handling)
Stripping
No release agent required in standard conditions
Processing
On-Site: functions comparable to polywood.
Industrial Production: optimized for precise cutting and drilling.
Board In Bundle
Thickness | 9 MM | 10 MM | 11 MM | 12 MM | 15 MM | 18 MM | 20 MM | 21 MM | 25 MM |
|---|---|---|---|---|---|---|---|---|---|
Number OF Boards In Bundle | 100 | 90 | 81 | 75 | 60 | 50 | 45 | 42 | 36 |
Product Specifications
Thickness | Modulus Of Elasticity | Static Bending | Allowable Stresses | Tensile Stress | Vicat Softening Temperature | Water Absorption Rate | Fire Retardant |
|---|---|---|---|---|---|---|---|
9 MM | 3500 | 52 | 28.43 | 15 | 85°C | <0.09% | Grade A |
12 MM | 3500 | 45 | 24.60 | 15 | |||
15 MM | 3000 | 38 | 20.78 | 13 | |||
18 MM | 2500 | 13 | 16.95 | 11 | |||
21 MM | 2000 | 24 | 13.12 | 11 | |||
27 MM | 1800 | 18 | 9.84 | 11 | |||
Test Method | ASTM D790 – 17 | ASTM D143-14 | ASTM D143-14 | ISO 527- 1:2019 | ASTM D790 – 17 | ASTMD570-22 | ASTM-E 84 |
For More Information
Download our m-board catalouge
